SINGLE POLE SERIES

SPST 36V 85A Continuous Duty Solenoid

Engineered for systems that never quit, this 12V continuous-duty solenoid is rated for sustained 65A loads without overheating. Packaged for retail with full hardware, its plated steel construction and insulated circuitry make it ideal for long-duration applications like lift gates, winch controls, and auxiliary power distribution.

Features

• Continuous Duty Solenoid SPST 36V 85A
• 4 stud, Insulated stud earth
• SPST Normally open (one circuit) OFF/ON
• Copper Stud terminals 5/16″-24
• Insulated Coil terminals 10-32
• Plated steel housing, nuts & washers Inc.
• Mounting holes 8mm x 15mm, 56mm CTC
• Mount with brand cap facing DOWN
• Int. ratings: 10 sec ON, 30 min OFF

Specifications

• Voltage: 36 Volt
• Amperage: 85A Continuous, 120A Make, 65A Break, 130 ohm
• Dimensions: H 60 x D 64 x W 84
• Configuration: SPST
• Modes: Continuous Duty
• Series: 24080 Series
