SINGLE POLE SERIES

SPST 225A Heavy Duty Solenoid Continuous

The 24812 series is a "latching" solenoid designed for maximum energy efficiency, drawing zero current while in the ON or OFF position. By utilizing a momentary pulse to switch states, it eliminates coil heat and battery drain, making it the definitive choice for long-term battery isolation and remote power management in commercial fleets.

Features

• SPST Normally open (one circuit) Off/On
• Copper Stud terminals 5/16”-24
• Insulated Coil terminals 10-32, L bracket
• Strong plated steel housing
• Plated steel nuts and washers included
• Mounting holes 8mm x 15mm, 56mm CTC
• Int. ratings: 10 sec Of, 30 min Off

Specifications

• Voltage: 12 Volt
• Amperage: 225A Continuous, 750A Make, 150A Break, 7.7 ohm
• Dimensions: H 103 x D 69 x W 100
• Configuration: SPST
• Modes: Continuous Duty
• Series: 24812 Series
• Application: Heavy Duty
