SINGLE POLE SERIES

SPST 12V 17.5 Ohm Continuous Solenoid

Built specifically for 24V heavy-duty systems, the 24213B provides dependable intermittent switching for high-torque starters and hydraulic systems. This bulk-packaged solenoid features a rugged steel case and specialized contact materials optimized to handle the higher arcing potential of 24V industrial electrical architectures.

Features

• 200 A continuous current rating
• 12 V coil and a coil impedance of 17.5 ohms
• Insulated coil design electrically isolates the studs from the housing
• SPST circuitry and normally open contacts
• Two large 5/16"-24 copper power studs and two small #10-32 steel coil studs (control circuit) are heavy and durable
• Flat bracket
• Included hex nuts and lock washers are bagged

Specifications

• Voltage: 12 Volt
• Amperage: 200 A continuous current rating
• Configuration: SPST
• Series: 24213 Series
