SINGLE POLE SERIES

SPST 12V 100A Continuous Nylon Solenoid

Built for environments where exposure is unavoidable, the 24512 series features a specialized sealed construction to protect against dust, moisture, and road splash. Rated for continuous duty at 12V, it is the definitive choice for long-duration loads like auxiliary lighting and cooling fans in commercial trucking and marine applications.

Features

• Continuous Duty Nylon Solenoid SPST 12V 100A
• SPST Normally open (one circuit) OFF/ON
• 2 blade, 2 stud, Copper Stud terminals 5/16″-24
• Internal grounded coil terminal 10-32, F bracket
• Gloss black nylon housing, nuts & washers inc
• Mounting holes 8mm x 15mm, 56mm CTC
• Int. ratings: 10 sec ON, 30 min OFF

Specifications

• Voltage: 13 Volt
• Amperage: 100A Continuous, 400A Inrush, 100A Make and Break, 16 ohm
• Dimensions: H 65 x D 47 x W 76
• Configuration: SPST
• Modes: Continuous Duty
• Series: 24512 Series
