REVERSE RELAY MODULE

Twin Motor Forward & Reverse Relay

Streamline your high-current power distribution with the 22452 series heavy-duty terminal block. Built to industrial standards with a rugged, non-conductive base and high-torque brass studs, this block provides a professional-grade solution for joining massive battery cables and primary electrical feeds. Its robust construction ensures low-resistance connections and maximum mechanical security in high-vibration commercial, marine, and emergency vehicle environments.

Features

• Twin Motor Forward & Reverse Relay Module
• Dynamic braking when switch turned OFF
• Heavy load current, dielectric strength 500V RMS
• Studs are securely protected in epoxy
• Low profile module (less than 50mm high)
• Fully sealed for harsh environment,
• Rust and moisture resistant plastic housing,
• Tin plated brass studs, vibration resistance: 10-55Hz
• For intermittent operation use switch: Mom On/Off/Mom On
• For continuous use switch: ON-OFF-ON
• Ideal for tarp, hoist, winch, fans and other motor reversing applications
• Automatically reverses direction of motors

Specifications

• Voltage: 12 Volt
• Amperage: 70A 5 min, 50A 3 min, 150A inrush
• Dimensions: H 48 x D 74 x W 92
• Configuration: DPDT
• Modes: Intermittent Duty
• Series: 24452 Series
