BI-STABLE LATCHING RELAYS
300 Amp Heavy-Duty High-Current Latching Relay
Ensure absolute electrical safety and prevent battery drain with the 880086 series Double-Pole Master Disconnect Switch. Built for heavy-duty commercial, agricultural, and emergency vehicle applications, this switch allows you to isolate two independent circuits with a single throw. Its rugged, weather-resistant construction and high-visibility red handle provide a professional-grade solution for emergency shut-offs and long-term storage protection in the most demanding environments.
Features
- Very low current draw to maintain closed circuit
- Remotely-operated 300A disconnect for high-amperage circuits
- Small control wires: eliminates the cost and weight of routing large copper cables
- Bi-stable (latched) operation draws no current in On or Off: eliminates a continuous demand on batteries.
- LED output wire enables remote indication of relay status – Open or Closed.
- Silver alloy contacts assure the lowest voltage drop / resistance and extends cycling life of the device.
- Stainless steel hardware and tin-plated copper contacts maximize resistance in harsh environments
Specifications
- Voltage: 12 Volt
- Amperage: 300A
- Approvals: IP66/IP69K
- Series: 880086 Series
